Band Saw Blades | Carbide Blades

Carbide Band Saw Blades



TCT


Features:   Applications:
- Ideal tool for cutting abrasive materials
- Tooth tips made of particularly wear-resistant carbidel

- For mineral building materials
- For graphite
- For sanded grey cast iron


Item group 540
TCT (approx. 1600 HV)


Tooth shape: T = trapezoid tooth


Duroset
Features:   Applications:
- Set carbide tipped band saw blade
- Bevelled, straight leading tooth
- Special division of the cutting channel
- Carbide with high wear resistance and toughness

- For treating steels and non-ferrous metals
- For universal use on all band sawing machines


Item group 541
DUROSET (approx. 1600 HV)


All items are also available with extra wide set for cutting non-ferrous metals.
Tooth shape: K = hook tooth


Ecodur
Features:   Applications:
- Economic alternative to start using carbide

- For aluminium and other materials that tend to form built-up edges
- For cross-sections up to 600 mm
- For materials up to a hardness of 60 HRC


Item group 542
ECODUR (approx. 1600 HV)


Tooth shape: T = trapezoid tooth
* Tooth pitch will be discontinued


Futura
Features:   Applications:
- Extreme running smoothness even with high cutting speeds / cutting rates
- With patented special grinding of the tooth edges, we were able to achieve a more favourable division of the cutting channel into 7 chip sections

- For increasing the cutting rate
- For zirconium and molybdenum
- For hardened steels up to max. 62 HRC
- For aluminium bronze and Ampco
- For titanium alloys


Item group 545
FUTURA (approx. 1600 HV)


Tooth shape: T = trapezoid tooth


Futura Plus
Features:   Applications:
- Unique combination due to its sophisticated geometry: coarse cutting in the centre of the cutting channel as well as plain machining on both cutting surfaces
- Best surface finish

- For the best surface finish
- For sanded aluminium and magnesium cast


Item group 546
FUTURA PLUS (approx. 1600 HV)


Tooth shape: T = trapezoid tooth


Futura SN
Features:   Applications:
- The tooth shape TSN, already tested and steadily improved over many years, is based on the proven tooth edge geometry of FUTURA. This gives incomparable stability to the precisely ground trapezoid teeth of FUTURA SN.
- FUTURA geometry with specially aligned rake angle

- For induction hardened and chrome coated shafts
- For hardened steel up to 62 HRC
- For hard manganese steel
- For hard-chrome plated work pieces
- For diameters up to 200 mm


Item group 547
FUTURA SN (approx. 1700 HV)


Tooth shape: TSN


Futura Premium
Features:   Applications:
- Top-quality product of the FUTURA line with special coating
- Clear increase of cutting rate and tool life for an even more economic cutting process.

- For case hardened and quenched and tempered steels
- For hot and cold work steels


Item group 548
FUTURA PREMIUM (approx. 3800 HV)


Tooth shape T: trapezoid tooth


TCgrit K
Features:   Applications:
- Band saw blade with continuous carbide coating.
- Especially for cutting work pieces of small dimensions

- For car tyres
- For ceramic plates
- For cables and wires
- For fibreglass


Item group 550
TCgrit K (approx. 1500 HV)


Coating: K = continuously carbide coating, alternative dimensions on request
* Sizes will be discontinued


TCgrit U
Features:   Applications:
- Intermittent carbide coating
- Advantageous chip flow with work pieces of larger crosssections

- For car tyres
- For fibreglass
- For high surface finish with large cross-sections


Item group 554
TCgrit U (approx. 1500 HV)


Coating: U = intermittent carbide coating, alternative dimensions on request
* Sizes will be discontinued


Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
