Band Saws | Vertical | Automatic | KASTOvericut A


The KASTOvericut A is a fully-automatic, high-performance vertical band saw designed for straight and miter cuts with angles from +60° to -45° (optional: +60° to -60°).

The cutting angle adjustment is done through the PLC control and the saw head is hydraulically clamped in position for highest accuracy. Single stroke of the highly accurate feeding system is 9.8’ and automatic Zero-Positioning for the first piece is standard.

The KASTO Universal Hydraulic UH guarantees best cutting performance. The feed rate can either be set constant when cutting solid materials or variable when cutting tubes or profiles to adapt to the section to be cut.

KASTO-like this machine is extraordinarily heavy built which results in extremely quiet operation, short cutting times and long blade life.

FEATURES

  • Fully Hydraulic
  • Fully Automatic
  • KASTO UH - Saw Feed Control
  • Automatic Adjustment of Cutting Angles
  • Hydraulic Saw Blade Guide Arm
  • Hydraulic Saw Blade Tension
  • Vises on Both Sides of the Saw Blade (Split Vise)
  • Clamping Pressure Adjustment
  • Integrated Machine Roller Table
  • Driven Chip Brush
  • Removable Chip Container
  • Micro Spray System
  • Integrated Flood Coolant System
  • KASTO CompactControl (PLC)

Technical Data
Shuttle Stroke 9.84' (single stroke)
Saw Band Dimensions 18' 6" x 1-1/2" x 0.05"
Saw Drive 5.4 hp
Blade Speed 39 - 394 FPM
Dimensions (W × L × H) 73" x 111" X 106"
Weight 6900 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R 60º R
inch Ø 18.1 Ø 16.7 Ø 11.8
mm Ø 460 Ø 425 Ø 300
inch 23.6 x 18.1 18.1 x 16.7 18.1 x 11.8
mm 600 x 460 460 x 425 460 x 300
inch 18.1 x 18.1 16.7 x 16.7 11.8 x 11.8
mm 460 x 460 425 x 425 300 x 300
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
