Band Saws | Block & Plate | Vertical

The KASTOvertical is the ideal machine for cutting smaller blocks, plates and samples.

By using bi-metal blades or carbide tipped blades, all material qualities, also difficult to cut material such as Titanium, Hastelloy, Inconel, can be cut with high cutting performances.

The smallest block and plate saw from KASTOfeatures a steady saw head and a moveable material support table driven by a precise ball screw spindle. Cutting speeds and feeds are electronically controlled and infinitely variable for best cutting performance and blade life.

FEATURES

  • Hydraulic Saw Blade Tension
  • Infinitely Variable Cutting Speed
  • Infinitely Variable Cutting Feed
  • Pre-tensioned Carbide Band Saw Guides
  • Blade Breakage / Slippage Monitor
  • KASTO Compact Control (PLC)
  • Pre-selection of Cutting Depth
  • Heavy Duty Saw Unit
  • Hour counter
  • Integrated Chip Tray
  • Powered Chip Brush
Technical Data
Cutting Range
Cutting length 4.1'
Cutting depth 26.8"
Cutting height 23.6"
Performance Characteristics
Saw Drive 5.4 hp
Voltage 440 V / 60 Hz / 3 -phase
Blade Speed 3 - 820 FPM
Saw Band Dimensions (L × H × W) 17' 10 ½" x 2" x 0.05"
Measures and Weight
Weight (max) 7055 lbs.
Length 100"
Width 93"
Height 110"
Table Support Width (outer table) 25.2"
Table Support Width (inner table) 25.2"
Table Support Height 45.3"
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
