Circular Saws (Steel) | High Performance Circular Saws | KASTOvariospeed C15


The KASTOvariospeed C15 is a fully automatic high performance circular saw with loading magazine and discharge / sorting device for cut pieces.

Without any changeover, the KASTOvariospeed adapts to different materials and profile shapes. Due to this fact, this machine is well suited for small and medium batch sizes in “lights-out” operation. Using modern machine design elements, idle times are reduced to a minimum – even with long cut-pieces (6.5’ in one stroke).

The heavy-duty construction of the machine together with the 25 hp, high-performance saw drive ensures shortest cutting times. The thin-cut technology guarantees minimum material loss.

The modular concept allows a magazine operation as well as the integration into fully automatic storage/sawing systems. Besides the standard sorting device, different handling systems up to a CNC-ready palletization are available on the outfeed side.

The KASTO saw control TechnoControl ensures highest operating comfort.

FEATURES

  • Universal Magazine to Buffer and Reload Material Bars with Different Cross Sections
  • Cut Piece Discharge and Sorting Device
  • Automatic Measuring of the Material Height
  • Automatic Measuring of the Material Width
  • Integrated Flood Coolant System
  • Integrated Spray Mist System
  • Overload Protection
  • Saw Feed via Ball Screw Spindle
  • Material Feed via Gripper Feeder
  • Saw Blade Guides for Accurate Cuts
  • Automatic
  • KASTO Techno Control with Colour Display
Technical Data
Shuttle Stroke 79"
Saw Blade Dimensions Ø 450 mm
Saw Drive 25 hp
Blade Speed 26 - 492 FPM
Dimensions (W × L × H) 154'' x 138'' x 92''
Weight 8800 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º
inch Ø 6.0
mm Ø 152
inch 6.1 x 4.7
mm 155 x 120
inch 5.3 x 5.3
mm 135 x 135
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
