Band Saws | Horizontal (straight) | Semi-Automatic | KASTOtwin U6


The KASTOtwin U6  is a high performance semi-automatic band saw in double column design. Because of the wide range of standard features, the rigid construction, the large cutting capacity and excellent price-performance ratio the machines of the KASTOtwin-series are the best selling KASTO machines in Canada.

The carbide band saw guides with anti-vibration rollers, heavy-duty guide arms and the 2-1/2” saw blade guarantee highest precision and cutting performance.

All functions of this machine are comfortably executed from the conveniently located CompactControl (PLC). In order to achieve optimum results for different kinds and shapes of material the machine is equipped with a frequency controlled saw drive with infinitely adjustable cutting speed and the proven KASTO UH-Hydraulic system can be set for constant feed rate or constant cutting force or the combination of both.

The standard safety package shuts the machine down in case of blade breakage, blade slippage or a lack of clamping pressure for safest operation.

FEATURES

  • Semi-Automatic
  • Fully-Hydraulic
  • KASTO UH-Hydraulic
  • Infinitely Variable Speed
  • Infinitely Adjustable Feed Control
  • PLC-Control (KASTO CompactControl)
  • Carbide Saw Blade Guides with Anti-Vibration Rollers
  • Linear Guided Split-Main Vise (Material Clamping on Both Sides of the Saw Blade)
  • Blade Breakage / Slippage Monitor
  • Clamping Pressure Monitor
  • Integrated Coolant System
  • Powered Chip Brush
  • Chip Drawer
Technical Data
Saw Band Dimensions 28' 5-1/2'' x 2-1/2'' x 0.063''
Saw Drive 10.2 hp
Blade Speed 66 - 361 FPM
Dimensions (W × L × H) 63'' x 170'' x 103''
Weight 12100 lbs.
Voltage 440 V / 60 Hz / 3 -phase

Cutting Capacity
0º
inch Ø 26.0
mm Ø 660
inch 31.5 x 26.0
mm 800 x 660
inch 26.0 x 26.0
mm 660 x 660
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
