Power Hack Saws | KASTOpsb 4


The KASTOpsb 4 is a fully hydraulic semi-automatic power Hacksaw.

The KASTOpsb hacksaws have proven themselves in countless applications over decades. They operate with a “pushing, arched cutting motion” – a KASTO invention that revolutionized metal cutting. Even today, saws using this technology prove their worth with their robust design and thrifty tool costs.

KASTOpsb hacksaws are designed for medium to heavy workshop use and are ideal for cutting profiles, beams and solids. They offer miter cutting capability, large cutting ranges and require minimal floor space. In addition KASTO power hacksaws are easy to operate and maintain.

FEATURES

  • Fully Hydraulic
  • Infinitely Variable Miter Adjustment
  • Pendulum Vise
  • Quick Clamping Measuring Stop
  • Six Cutting Speeds
  • Infinitely Adjustable Cutting Pressure
  • Lifting Movement in the Idle Stroke
  • Miter Cutting from 0° to 45°
  • Automatic Switch off after Finished Cut
  • Integrated Coolant System
  • Triple Pivot Bearing of Saw Head
Technical Data
Saw Band Dimensions 11.6" x 2" x 0.079"
Saw Drive 5.4 hp
Blade Speed 36 / 43 / 56 / 72 / 85 / 112 FPM
Dimensions (W × L × H) 28" x 72" x 46"
Weight 1600 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R
inch Ø 9.8 Ø 15.7
mm Ø 250 Ø 400
inch 9.8 x 9.8 15.7 x 9.4
mm 250 x 250 400 x 240
inch 9.8 x 9.8 12.6 x 12.6
mm 250 x 250 320 x 320
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
