Band Saws | Block & Plate | KASTOplate U3

The KASTOplate U3 is the ideal machine for cutting smaller blocks and plates with a height of up to 12.6” and a maximum weight of 13,200 lbs. Due to the excellent accessibility of the material, this machine is also very well suited to the cutting of remnants.

The KASTObloc provides an outstanding balance in price and accuracy. We call it the “light” version of big brother KASTObbs. However this machine is anything but light.

It has all the advantages of the “big one” – the same feed unit, same cutting performance, same cutting accuracy as well as same very easy access. All work pieces on the table can be reached by hand and the integrated chip conveyor and coolant system guarantee clean operating.

The KASTObloc can be upgraded to a fully-automatic block band saw with automatic material feed!

FEATURES

  • Chip Conveyor
  • Powered Chip Brush
  • Integrated Cooling System
  • Infinitely Variable Cutting Speed
  • Easy and Fast Saw Blade Change
  • Digital Preselection of Cutting Length
  • KASTO CompactControl for Easy Operating
  • Hydraulic Adjustment of Saw Blade Guide Arm
  • Hydraulic, Electronic Supervised Saw Blade Tension
  • Mechanical Measuring Stop with Digital Display, Fast and Easy to Adjust
Technical Data
Cutting Range
Cutting Length up to 13.5'
Cutting Depth 26''
Cutting Height 12.6"
Performance Characteristics
Saw Drive 5.4 hp
Voltage 440 V / 60 Hz ; 3 phases
Blade Speed 56 - 361 FPM
Saw Band Dimensions (L × H × W) 17' 10-½'' x 1-½'' x 0.05''
Measures and Weight
Weight (max) 18800 lbs.
Length 15'
Width 103''
Height 126''
Table Support Width (outer table) 26''
Table Support Width (inner table) 26''
Table Support Height 47.2''
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
