Power Hack Saws | KASTOhbs 1


The KASTOhbs 1is a fully hydraulic semi-automatic power Hacksaw.

The KASTOhbs hacksaws have proven themselves in countless applications over decades. They operate with a “pushing, arched cutting motion” – a KASTO invention that revolutionized metal cutting. Even today, saws using this technology prove their worth with their robust design and thrifty tool costs.

KASTOhbs hacksaws are designed for light to medium workshop use and are ideal for cutting profiles, beams and solids. They offer miter cutting capability, large cutting ranges and require minimal floor space. In addition KASTO power hacksaws are easy to operate and maintain.

FEATURES

  • Fully Hydraulic
  • Infinitely Variable Miter Adjustment
  • Pendulum Vise
  • Quick Clamping Measuring Stop
  • Two Cutting Speeds
  • Infinitely Adjustable Cutting Pressure
  • Lifting Movement in the Idle Stroke
  • Miter Cutting from 0° to 45°
  • Automatic Switch off after Finished Cut
  • Integrated Coolant System
Technical Data
Saw Band Dimensions 3.7" x 1.2" x 0.059"
Saw Drive 1.1 hp
Blade Speed 52 / 105 FPM
Dimensions (W × L × H) 19" x 47" x 32"
Weight 375 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R
inch Ø 5.9 Ø 8.3
mm Ø 150 Ø 210
inch 5.1 x 8.3 9.4 x 7.5
mm 130 x 210 240 x 190
inch 5.7 8.3
mm 145 210
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
