Circular Saws (Steel) | Mitering | Semi-Automatic | KASTOflex U


The KASTOflex U  is a semi automatic circular saw well suited to a wide range of applications in the workshop as well as in production.

The saw blade is located underneath the machine table that rotates and offers miter cutting capability in both directions. This unique design allows to clamp all shapes very easily and makes this machines the ideal solution when clamping fixtures have to bee used.

The heavy-duty construction of this machine together with the infinitely variable saw feed guarantee highest accuracy and performance whether solids or tubes are cut.

In order to meet latest safety requirements and reduce the noise level, the KASTOflex comes fully enclosed.

FEATURES

  • Semi-Automatic
  • 2-Speed Saw Drive (Variable Drive optional)
  • Miter Cutting Range: -45° to 60°
  • Fast Cutting Angle Adjustment
  • Infinitely Variable Cutting Feed
  • Chip Drawer (Conveyor Optional)
  • Integrated Cooling System
  • Large Maintenance Door
  • Chip Removal Brush
  • Total Enclosure
  • Cutting Depth Adjustment
Technical Data
Saw Blade Dimensions Ø up to 450 mm
Saw Drive (alternative) 1.9 / 3 hp (5.4 hp)
Blade Speed (alternative) 39 / 79 FPM (33 - 197 FPM)
Dimensions (W × L × H) 47" x 82" x 74"
Weight 3300 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R/L 60º R
inch Ø 5.9 Ø 5.7 Ø 4.5
mm Ø 150 Ø 145 Ø 115
inch 7.9 x 3.9 6.3 x 3.1 4.7 x 2.4
mm 200 x 100 160 x 80 120 x 60
inch 5.5 x 5.5 4.7 x 4.7 3.9 x 3.9
mm 140 x 140 120 x 120 100 x 100
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
