Circular Saws (Steel) | Mitering | Automatic | KASTOflex A


The KASTOflex A is a fully automatic circular saw well suited to a wide range of applications in workshops as well as in production.

The saw blade is located underneath the machine table that rotates and offers miter cutting capability in both directions. This unique design allows to clamp all shapes easily and makes this machine very flexible. The feeding system is driven by a precise ball screw spindle and offers a very long stroke of 78.7". All functions of the machine can be easily executed from the conveniently located control panel of the KASTO CompactControl (PLC).

The heavy-duty construction of this machine together with the infinitely variable saw feed guarantee highest accuracy and performance whether solids or tubes are cut.

In order to meet latest safety requirements and reduce the noise level, the KASTOflex comes fully enclosed.

FEATURES

  • Fully Automatic
  • Automatic Material Feeding System
  • 2-Speed Saw Drive
  • Miter Cutting Range: -45° to 60°
  • Fast Cutting Angle Adjustment
  • Infinitely Variable Cutting Feed
  • PLC-Control (KASTO Compact Control)
  • Integrated Cooling System
  • Cutting Depth Adjustment
  • Large Maintenance Door
  • Chip Removal Brush
  • Total Enclosure
Technical Data
Shuttle Stroke 78.7"
Saw Blade Dimensions Ø up to 450mm
Saw Drive 1.9 / 3 hp (5.4 hp)
Blade Speed 39 / 79 FPM (33 - 197 FPM)
Dimensions (W × L × H) 47" x 129" x 74"
Weight 5500 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R / L 60º R
inch Ø 5.9 Ø 5.7 Ø 4.5
mm Ø 150 Ø 145 Ø 115
inch 7.9 x 3.9 6.3 x 3.1 4.7 x 2.4
mm 200 x 100 160 x 80 120 x 60
inch 5.5 x 5.5 4.7 x 4.7 3.9 x 3.9
mm 140 x 140 120 x 120 100 x 100
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
