Circular Saws (Steel) | Mitering | Automatic | KASTOflex A-NC


The KASTOflex A-NC is a fully automatic circular saw well suited to a wide range of applications in workshops as well as in production.

The saw blade is located underneath the rotating NC-controlled machine table. This unique design allows to clamp all shapes easily and makes this machine very flexible. The pre-selection of cutting angles as well as all other functions of the machine are easily executed from the conveniently located control panel of the KASTO CompactControl (PLC). The feeding system is driven by a precise ball screw spindle and offers a very long stroke of 78.7".

The heavy-duty construction of this machine together with the infinitely variable cutting speeds and feeds guarantee highest accuracy and performance whether solids or tubes are cut.

In order to meet latest safety requirements and reduce the noise level, the KASTOflex comes fully enclosed.

FEATURES

  • Fully Automatic
  • Automatic Cutting Angle Adjustment
  • Automatic Material Feeding System
  • Infinitely Variable Cutting Speed
  • Infinitely Variable Cutting Feed
  • Miter Cutting Range: -45° to 60°
  • PLC-Control (KASTO Compact Control)
  • Integrated Cooling System
  • Cutting Depth Adjustment
  • Large Maintenance Door
  • Chip Removal Brush
  • Total Enclosure
Technical Data
Shuttle Stroke 78.7"
Saw Blade Dimensions Ø up to 450 mm
Saw Drive 5.4 hp
Blade Speed 33 - 197 FPM
Dimensions (W × L × H) 47" x 129" x 74"
Weight 5500 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R/L 60º R
inch Ø 5.9 Ø 5.7 Ø 4.5
mm Ø 150 Ø 145 Ø 115
inch 7.9 x 3.9 6.3 x 3.1 4.7 x 2.4
mm 200 x 100 160 x 80 120 x 60
inch 5.5 x 5.5 4.7 x 4.7 3.9 x 3.9
mm 140 x 140 120 x 120 100 x 100
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
