Circular Saws (Steel) | Mitering | Automatic | KASTOdisc A10


The KASTOdisc A10 is a fully automatic circular saw well suited to a wide range of applications in the workshop as well as in production. The machine is equipped with a ball screw spindle driven infeed shuttle and the adjustment of miter cutting angles from -45° to +45° is fast and simple.

The proven KASTO CompactControl (PLC) offers all the features of even bigger machines and is conveniently located in front of the machine. The 350 mm saw blade guarantees a large cutting capacity.

The machine is equipped with 2 hydraulic clamping devices for safe material clamping and the double main vise reduces burrs to a minimum.

FEATURES

  • Fully-Automatic
  • Fully Hydraulic
  • Comfortable PLC Control
  • Miter Cutting Range: -45° to +45°
  • Double Clamping Vise (Main Vise)
  • Ball Screw Spindle Infeed Shuttle
  • Clamping Pressure Regulation
  • Easy to Read Angel Scale
  • Integrated Coolant System
  • Rigid Cast Iron Saw Base
  • Infinitely Variable Speed
  • Chip Knocker Wheel
  • Chip Drawer
Technical Data
Shuttle Stroke 22"
Saw Blade Dimensions 350 mm x 2.5 mm x 32 mm
Saw Drive 3.5 / 4.6 hp
Blade Speed 38 - 192 FPM
Dimensions (W × L × H) 55'' x 59'' x 75''
Weight 2200 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R / L
inch Ø 3.9 Ø 3.9
mm Ø 100 Ø 100
inch Ø 4.7 Ø 4.7
mm Ø 120 Ø 120
inch 6.7 x 3.9 5.1 x 3.9
mm 170 x 100 130 x 100
inch 3.9 x 3.9 3.9 x 3.9
mm 100 x 100 100 x 100
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
