The BOMAR transverse 820.450 DGS is a semi-automatic double column saw with miter cutting capability in both directions. It is the perfect machine for cutting profiles and bundles due to its big cutting range and the canted saw blade with at an angle of 6°.

Due to a unique design the machine table turns with the saw head which avoids cutting into the table. Special clamping vises clamp that the material always directly right at the saw blade and the additional top clamping device ensures safe clamping at any time.

Turning of the saw frame is done hydraulically and can be comfortably controlled from the free standing control panel. Precise linear guides, carbide saw blade guides and automatic cutting pressure regulation on both band guides in combination with the rigid construction guarantee accurate cuts, high cutting performance and excellent blade life.

In combination with BOMAR infeed systems and or measuring stops this machine can be upgraded to a fully automatic cutting line.

FEATURES Digital Angle Display Miter Cutting Range: -60° to 60° Saw Blade Tension & Breakage Monitor Automatic Cutting Pressure Regulation Safety Switch on Band Wheel Door Big Removable Chip Container Robust Cast Iron Machine Base Digital Cutting Speed Display Infinitely Adjustable Speed Carbide Band Saw Guides Integrated Coolant System Driven Chip Brush Fully Hydraulic CNC Control

View Specifications | Download PDF

Technical Data
Saw Band Dimensions (L × H × W)	21' 2-½'' x 1 ½'' x 0.05''
Saw Drive	5.4 hp
Blade Speed	66 - 295 FPM
Dimensions (W × L × H)	63'' x 148'' x 98''
Weight	620 lbs.
Voltage	Various Voltages Available

Cutting Capacity
			0º		45º L/R		60º L/R
	inch		Ø 17.7		Ø 17.7		Ø 14.2
	mm		Ø 450		Ø 450		Ø 360
	inch		32.3 x 17.7		22.0 x 17.7		14.2 x 17.7
	mm		820 x 450		560 x 450		360 x 450
	inch		32.3 x 17.7		22.0 x 17.7		14.2 x 17.7
	mm		820 x 450		560 x 450		360 x 450
	inch		17.7 x 17.7		17.7 x 17.7		14.2 x 14.2
	mm		450 x 450		450 x 450		360 x 360
