The BOMAR transverse 510.330 GANC is a fully automatic pivot-style band saw with a large cutting range, comfortable and simple handling and an excellent cutting performance.

The feeding length is 23.6'' in one stroke and is measured by a high resolution linear measuring system. The feeding vise is located in a floating bed and guided in precise linear guides.
The continuous roller table integrated in the machine with cover plates in between the rollers guarantees reliable material feeding of even short pieces.

The automatic mode allows miter cuts with angles up to 45° and in the semi-automatic mode even cuts with angles up to 60° are possible. Due to big drive and idler wheels, the infinitely adjustable cutting speed and the precisely guided saw blade, long blade life, excellent cutting results and a high cutting performance are guaranteed.

FEATURES Fully Hydraulic Fully Automatic Infinitely Adjustable Speed Miter Cutting Range: 0° to 60° Hydraulic Controlled Down Feed Safety Switch on Band Wheel Door Automatic Height Setting of the Saw Head Saw Blade Tension & Breakage Monitor Digital Speed Control Display Carbide Saw Blade Guides Integrated Coolant System 23.6'' Shuttle Infeed Shuttle Hydraulic Clamping Vise End-of-material Switch Digital Angle Display Feed Force Control Driven Chip Brush

View Specifications | Download PDF

Technical Data
Shuttle Stroke	23.6''
Saw Band Dimensions (L × H × W)	15' 8'' x 1 1/4'' x 0.042''
Saw Drive	4.1 hp
Blade Speed	66 - 295 FPM
Dimensions (W × L × H)	71'' x 96'' x 71''
Weight	3400 lbs.
Voltage	Various Voltages Available

Cutting Capacity
			0º		45º R		60º R
	inch		Ø 13.0		Ø 13.0		Ø 9.8
	mm		Ø 330		Ø 330		Ø 250
	inch		20.1 x 13.0		15.7 x 3.9		10.2 x 3.9
	mm		510 x 330		400 x 100		260 x 100
	inch		20.1 x 13.0		11.4 x 13.0		5.9 x 13.0
	mm		510 x 330		290 x 330		150 x 330
	inch		13.0 x 13.0		12.2 x 12.2		8.7 x 8.7
	mm		330 x 330		310 x 310		220 x 220
