Band Saws | Scissor Type | Manual | Bomar pulldown 295.230DG

The BOMAR pulldown 295.230 DG manual band saw is THE universal workshop machine.
The rigid, vibration damping cast-iron saw head together with a strong saw drive guarantee accurate cuts and long machine life.

The 1"-saw blade guided in precise carbide guide and the miter cutting capability in both directions make this machine not only to one of the toughest but also to one of the most versatile machines in its class.

FEATURES

  • Length Measuring Stop
  • Carbide Saw Blade Guides
  • Miter Cutting 45° left and 60° right
  • Safety Switches on Band-wheel Door
  • Saw Blade Guard for Safe Operation
  • Integrated Coolant System
  • Blade Breakage Switch
  • Quick-Clamping Vise
  • Chip Removal Brush
  • 2-speed Motor

Technical Data
Saw Band Dimensions (L × H × W) 8' 11'' × 1" × 0.035"
Saw Drive 1.5 / 2 hp
Blade Speed 115 / 230 FPM
Dimensions (W × L × H) 25" × 56" ×59"
Weight 730 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R 45º L 60º R
inch Ø 9.1 Ø 7.5 Ø 6.7 Ø 4.7
mm Ø 230 Ø 190 Ø 170 Ø 120
inch 11.6 x 5.1 7.5 x 5.5 7.7 x 2.4 4.1 x 4.1
mm 295 x 130 190 x 140 195 x 60 105 x 105
inch 10.2 x 9.1 7.1 x 9.1 3.1 x 8.7 4.1 x 4.1
mm 260 x 230 180 x 230 80 x 220 105 x 105
inch 9.1 x 9.1 7.1 x 7.1 5.9 x 5.9 4.1 x 4.1
mm 230 x 230 180 x 180 150 x 150 105 x 105
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
