The BOMAR individual 610.440 GH semi automatic double column band saw features beside a heavy saw frame and a powerful industrial saw drive also a large number of other standard equipment that satisfies even the highest demands. With miter cutting capability in one direction this machine is suitable for a wide range of different applications.

The 1-1/2" saw blade guided in precise carbide guides together with the vibration damping cast iron machine base guarantee highest accuracy and cutting performance. The machine is equipped with large drive and idler wheesl for long blade life. Operation of the machine is fast and simple due to the free standing control panel with PLC-control and the full stroke clamping vise.

The heavy-duty design in combination with all with the big amount of standard features makes this machine to one of the most versatile bandsaws out there.

FEATURES Fully Hydraulic Feed Force Control Semi-Automatic Cutting Cycle Miter Cutting Range: 0° to 60° Hydraulic Controlled Down Feed Saw Blade Tension & Breakage Monitor Automatic Height Setting of the Saw Head Safety Switch on Band Wheel Door Free Standing PLC Control Integrated Coolant System Carbide Saw Blade Guides Infinitely Adjustable Speed Hydraulic Clamping Vise Adjustable Length Stop Chip Removing Brush Digital Speed Display Digital Angle Display

View Specifications | Download PDF

Technical Data
Saw Band Dimensions (L × H × W)	21' x 1-1/2'' x 0.05''
Saw Drive	5.4 hp
Blade Speed	66 - 295 FPM
Dimensions (W × L × H)	71'' x 126'' x 86''
Weight	3400 lbs.
Voltage	Various Voltages Available

Cutting Capacity
			0º		45º R		60º R
	inch		Ø 17.3		Ø 17.3		Ø 13.8
	mm		Ø 440		Ø 440		Ø 350
	inch		25.0 x 17.3		20.7 x 9.8		13.8 x 9.8
	mm		635 x 440		525 x 250		350 x 250
	inch		25.0 x 17.3		16.1 x 17.3		9.1 x 17.3
	mm		635 x 440		410 x 440		230 x 440
	inch		17.3 x 17.3		16.1 x 16.1		9.1 x 9.1
	mm		440 x 440		410 x 410		230 x 230
