Band Saws | Scissor Type | Manual | BOMAR economic 410.260 DG

The BOMAR economic 410.260 DG is a manual band saw with an excellent price-performance ratio and a large cutting capacity. Due to its miter cutting capability in both directions it is suitable for a wide range of applications.

The 1" saw blade and the precise carbide saw blade guides guarantee highest accuracy and cutting performance combined with long blade life.

The control panel is conveniently located on the side of the machine. The adjustment of the cutting angles from -45° to +60° as well as the material clamping via the standard quick-clamping vise is fast and simple.

The saw feed is achieved due to the weight of the saw head while the feed rate is infinitely adjustable from the control panel. Lift of the saw head is manual.

FEATURES

  • 3-Speed Saw Drive
  • Miter Cutting Range: -45° to 60°
  • Saw Blade Tension & Breakage Monitor
  • Safety Switch on Band Wheel Door
  • Big Removable Chip Container
  • Carbide Saw Blade Guides
  • Integrated Coolant System
  • Adjustable Length Stop
  • Chip Brush
Technical Data
Saw Band Dimensions (L × H × W) 12’ 5-1/2’’ x 1’’ x 0.035’’
Saw Drive 2.0 hp
Blade Speed 89 / 200 / 303 FPM
Dimensions (W × L × H) 33’’ x 87’’ x 52’’
Weight 1100 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R 45º L 60º R
inch Ø 10.8 Ø 10.6 Ø 10.6 Ø 7.9
mm Ø 275 Ø 270 Ø 270 Ø 200
inch 16.3 x 9.4 11.8 x 4.7 11.8 x 3.9 7.9 x 3.9
mm 415 x 240 300 x 120 300 x 100 200 x 100
inch 7.1 x 10.8 9.4 x 10.6 5.5 x 10.6 5.1 x 10.6
mm 180 x 275 240 x 270 140 x 270 130 x 270
inch 10.6 x 10.6 9.8 x 9.8 10.6 x 10.6 7.1 x 7.1
mm 270 x 270 250 x 250 270 x 270 180 x 180
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
