Band Saws | Vertical | Semi-Automatic | BOMAR SV 330 DGH


The BOMAR SV 330 DGH is a semi-automatic vertical band saw for a large variety of applications. This hydraulic machine features a large machine table with T-slots in order to be able to clamp and cut parts with all different kinds of shapes. The machine is designed for straight and miter cutting in both directions. The saw head can be locked so that even manual cuts can be done.

FEATURES

  • Semi-Hydraulic Cycle
  • Hydraulic Saw Feed
  • Miter Cutting Range: -60° to 60°
  • Chip Removing Brush
  • Blade Breakage Switch
  • Carbide Band Saw Guides
  • Integrated Coolant System
  • Safety Switch on Band Wheel Door
  • Ergonomic Design of the Machine
  • Two Speed Motor
Technical Data
Saw Band Dimensions (L × H × W) 12' 2-½'' x 1'' x 0.035''
Saw Drive 1.5 / 2.0 hp
Blade Speed 118 / 230 FPM
Dimensions (W × L × H) 30'' x 53'' x 79''
Weight 900 lbs.
Voltage Various Voltages Available

Cutting Capacity
0º 45º R 45º L 45º L 60º L
inch Ø 12.6 Ø 10.4 Ø 10.4 Ø 5.9 Ø 7.1
mm Ø 320 Ø 265 Ø 265 Ø 150 Ø 180
inch 12.6 x 13.0 12.6 x 10.4 12.6 x 10.4 12.6 x 5.9 12.6 x 7.1
mm 320 x 330 320 x 265 320 x 265 320 x 150 320 x 180
inch 12.6 x 13.0 12.6 x 10.4 12.6 x 10.4 12.6 x 5.9 12.6 x 7.1
mm 320 x 330 320 x 265 320 x 265 320 x 150 320 x 180
inch 12.6 x 12.6 10.4 x 10.4 10.4 x 10.4 5.9 x 5.9 7.1 x 7.1
mm 320 x320 265 x 265 265 x 265 150 x 150 180 x180
Specifications subject to change without notice. Not responsible for typographical errors.
Machines may be shown with optional equipment.
